As well as the jib halyard you also have the main halyard that pulls the mainsail up and down. THE BOOM. Attached to the mast at right angles to it is a straight piece of metal called the boom. This is where the foot of the mainsail goes, with the tack attached to the cunningham and the clew attached to the outhaull. Single Line Reefing. Since more and more boats these days are leading the halyards aft, single line reefing has become a very popular method for reefing your mainsail. Single line reefing essentially means that the outboard and inboard reef cringles use one line to tuck (or haul down) both ends of the sail. In general, this system is configured in two ways:

A mainsail ("mains'l") is a sail attached to the main mast. The principal types include: (1) A square-rig mainsail is a square sail attached at the bottom of the main mast. (2) A Bermuda-rig mainsail is a triangular sail with the luff attached to the mast with the foot or lower edge generally attached to a boom.

How to reef a mainsail diagram

To reef then, take the load off the mainsail by motoring into wind or by using the jibsail to head onto a close haul or close reach and then let out the mainsheet until the load is removed from the mainsail. Wrap the main halyard around a winch and release the clutch for the halyard. Lower the mainsail to the desired reefing point. Mainsail Reefing Setup. There are a number of effective reefing arrangements, but all have two common elements. The first is ease of use; the reef should be easy to set and shake. Second, the reefed sail must have a shape appropriate for the conditions, which means flat. The reefing system must pull the clew out along the boom, like an outhaul ... Point A is a reef tack, Point D is the reef clew, and points in-between are reef points, which are mainly used to bundle up the sail so the bunt of the sail doesn't blow around or chafe. The reef tack is usually attached to a tack hook on the goose neck of the boom. The reef clew is setup as per Giu's diagram.


Jiffy Reefing System. Jiffy Reefing is a very easy project if you have the gromets all ready on the Main. In the picture below I show the rigging of a Jiffy Reefing System. The Main and Boom are transparent so you can follow the flow of the Reefing Line. For this Project you will need: 1. Length of 1/4" line. 2. 3 screw down eye straps. To reef a dinghy sail when afloat, heave-to, lower the mainsail and have one crew at the tack and one at the clew. Tuck 6 inches of the leech around the boom then roll it, pulling the sail tight with each roll while removing battens. ... Mainsail rigging diagram and sailboat traveler systems are part of rigging a dinghy. Share this Page. To upgrade a simple slab reef system, you should replace the regular reefing cringles with turning blocks of some sort to keep the friction to a minimum. Leaving the leech cringles as standard, simply reeving the line through the ring and down to the boom, adds to the already excessive friction in the system. Start by freeing the mainsheet and possibly moving the traveler to leeward to decrease the wind's pressure on the mainsail. 3) Take in the topping lift, to support the weight of the boom whilst you take in your reef. 4) Make sure that the main halyard is free to run without forming a knot against the jammer.

Joined Apr 9, 2003. ·. 934 Posts. #7 · Aug 11, 2011. When I had my Catalina 30, she had single line reefing with the reefing line traveling inside the boom. This came standard on my 1996 model boat. But like others have said; Catalina has made many changes over the years so there is quite a bit of variation. On a jib, the sheet is connected to the clew; on a mainsail, the sheet is connected to the boom (if present) near the clew. Clews are the lower two corners of a square sail. Square sails have sheets attached to their clews like triangular sails, but the sheets are used to pull the sail down to the yard below rather than to adjust the angle it ... Mainsail Reefing. It is good tradecraft for a sailor to reef the mainsail before they have to - and a lot easier. When reefing, the most important thing is to protect the luff of the sail. Whether you have a bolt rope main or a slide main, something is likely to get broken if you don't have the luff tension on first. Before describing how to put in a reef, you need to rig the reef outhaul correctly so that when you tighten it, the reef clew is pulled aft and down. The diagram shows the proper way to rig the reef line. Pull it from the end of the boom, up to the reef clew, down over the boom and under the foot of sail, under the boom and end it with a ...

Reefs How Many And How Deep Attainable Adventure Cruising

When you reef the mainsail, the line should pull the cringle downward and aft without binding. Position of the cheek block (left) and eye strap (on opposite side of the boom) 4. At the forward end of the boom, mount the other cheek block on the same side as the first cheek block. Align the block parallel to the boom and point it forward like in ...
